Editor’s note: This is one of a series of articles focused on the Conti ransomware family, which include a detailed analysis of a Conti attack, A Conti Ransomware Attack Day-By-Day, and a guide for what IT administrators can expect when Conti ransomware hits.
For the past several months, both SophosLabs and the Sophos Rapid Response team have been collaborating on detection and behavioral analysis of a ransomware that emerged last year and has undergone rapid growth. The ransomware, which calls itself Conti, is delivered at the end of a series of Cobalt Strike/meterpreter payloads that use reflective DLL injection techniques to push the malware directly into memory.
Sophos XG Firewall is packed with advanced protection to detect and block ransomware attacks and stop hackers moving laterally around your network to escalate privileges. AI-powered threat protection, including sandboxing, detects ransomware at the gateway.
Because the reflective loaders deliver the ransomware payload into memory, never writing the ransomware binary to the infected computer’s file system, the attackers eliminate a critical Achilles’ heel that affects most other ransomware families: There is no artifact of the ransomware left behind for even a diligent malware analyst to discover and study.
- However, security solutions providers are developing new defenses. For example, Sophos Intercept X, released last year, uses a new security capability developed specifically for ransomware. Its CryptoGuard feature looks for the telltale signs of ransomware, rather than signatures that identify attackers.
- Let's see what happens when Sophos Intercept X Advanced endpoint protection goes up against ransomware. Learn more at Sophos.com/Intercept-X.
That isn’t to say there aren’t artifacts and components to look at. The threat actors involved in attacks using Conti have built a complex set of custom tooling designed not only to obfuscate the malware itself, when it gets delivered, but conceal the internet locations from which the attackers have been downloading it during attacks, and prevent researchers from obtaining a copy of the malware that way as well.
Two-stage loading process
The first stage of the Conti ransomware process involves a Cobalt Strike DLL, roughly 200kb in size, that allocates the memory space needed to decrypt and load meterpreter shellcode into system memory.
The shellcode, XORed in the DLL, unfurls itself into the reserved memory space, then contacts a command-and-control server to retrieve the next stage of the attack.
This C2 communication is distinctive for a number of reasons. First, the malware appears to be using a sample Cobalt Strike configuration script named trevor.profile, published on a public Github archive. The profile serves as a sort of homage to an incident in which security researchers attending a conference found an insect in a milkshake at a restaurant outside the conference center.
But it doesn’t appear that the Conti attackers have modified this sample script very much, which makes the C2 communication notable in two ways: The script designates certain characteristics used during this phase of the attack, including a User-Agent string (“Mozilla/5.0 (Windows NT 6.1) AppleWebKit/537.36 (KHTML, like Gecko)“) that mimics that of a computer running Windows 7 but, distinctively, fails to identify the specific browser; and a static URI path (“/us/ky/louisville/312-s-fourth-st.html“) that includes the address of the infamous restaurant where the researcher discovered the bug in their shake.
The initial connection to the C2 server is to a page named Menus.aspx on the server; That page delivers the next payload, which the first one loads into memory — another Cobalt Strike shellcode loader that contains the reflective DLL loader instructions.
If that works successfully, the malware then contacts the “312-s-fourth-st.html” page on the same C2 server. The attackers only trigger these chains of events during an active attack, placing the ransomware binary on the C2 server so that it can be retrieved by this process only while the attack is ongoing, and removing it immediately afterwards.
Elusive ransomware payloads
Because of the ephemeral nature of the placement of the ransomware payload, analysts had difficulty obtaining samples for research. But we were able to salvage some of the in-memory code from infected computers where the malware was still running.
The ransomware process is not particularly unique, but it does reveal the ransomware creator’s ongoing interest in thwarting analysis by security researchers.
The ransomware itself uses a relatively common anti-analysis technique sometimes referred to as “API-by-hash,” in which Conti uses hash values to call specific API functions; Conti has an added layer of encryption over the top of these hashes to futher complicate the work of a reverse engineer. The malware has to perform two cycles of decryption on itself in order to perform those functions.
Among the behavior observed by responders, the ransomware immediately begins a process of encrypting files while, at the same time, sequentially attempting to connect to other computers on the same network subnet, in order to spread to nearby machines, using the SMB port.
Conti’s developers have hardcoded the RSA public key the ransomware uses to perform its malicious encryption into the ransomware (files are encrypted using the AES-256 algorithm). This isn’t unusual; It means that it can begin encrypting files even if the malware is unable to contact its C2.
Unfortunately, that isn’t the only threat this ransomware poses to its targets: Conti ransomware has also adopted a “leaks” site like several other ransomware threat actor groups. The attackers spend some time on the target network and exfiltrate sensitive, proprietary information to the cloud (in recent attacks, the threat actors have used the cloud storage provider Mega).
Under a header labeled YOU SHOULD BE AWARE! , the ransom note threatens, “Just in case, if you try to ignore us. We’ve downloaded a pack of your internal data and are ready to publish it on out (sic) news website if you do not respond. So it will be better for both sides if you contact us as soon as possible.”
Detection guidance
Conti ransomware, on its own, is unable to bypass the CryptoGuard feature of Sophos Intercept X; Our endpoint products may detect components of Conti under one or more of the following definitions: HPmal/Conti-B, Mem/Conti-B, Troj/Swrort-EZ, Troj/Ransom-GEM, or Mem/Meter-D. Network protection products like the Sophos XG firewall can also block the malicious C2 addresses to prevent the malware from retrieving its payloads and completing the infection process.
Sophos Intercept X Ransomware Download
Indicators of compromise for malware samples examined in this research has been posted to the SophosLabs Github.
Network Attached Storage (NAS) company Synology has issued an urgent warning for owners to check their box’s security settings after it emerged cybercriminals are targeting numerous NAS vendors with a new wave of ransomware.
At first it was thought that recent attacks could be exploiting an unknown software vulnerability in Synology’s products, but according to the company it has since been established that the attackers’ method is a much simpler but still effective brute-forcing of admin credentials.
Synology’s Manager of Security Incident Response Team, Ken Lee, wrote:
We believe this is an organised attack. After an intensive investigation into this matter, we found that the attacker used botnet addresses to hide the real source IP.
Spotted on 19 July 2019, the campaign involves trying lots of commonly used passwords on internet-connected NAS boxes. The attackers hope that eventually they’ll hit on a password that allows them the access necessary to encrypt the data on it.
The first symptom of this will be a ransom note in a readme file – typically asking for thousands of dollars-worth of bitcoins – to decrypt the data.
When you strip away the techniques used to hide the source IP, this isn’t a complex attack. That’s good news because it means that it’s also not difficult to defend against as long as owners check and enable specific security settings (see below).
Unfortunately, that means it’s also not hard to compromise a weakly defended NAS, which has led to a number of users being locked out of large volumes of data.
Warning: this campaign doesn’t only target Synology NAS boxes – the same techniques are being used to target other vendors’ products too.
In other recent incidents affecting another NAS vendor, QNAP, earlier in July, the ransomware involved was eCh0raix (probably the culprit in the latest Synology campaign) which you can read more about on the site of the security company that first noticed it.
What to do
Synology lists a number of basic defences, starting with the need to set a long and complex admin password (brute-force attacks succeed against shorter, simpler ones) before doing the same for everyone else who accesses data on the device.
The simplest way to make sure this has been done on a Synology NAS is to enable the ‘force users to change passwords after the administrator resets the password’ setting in the management console.
A second setting is the ‘apply password strength rules’ after deciding what this should mean (for example, forcing users to include mixed cases, special characters, numerals while excluding names and user descriptions).
Synology also recommends:
- Creating a new account in the administrator group and disabling the “admin” account.
- Enabling Auto Block in Control Panel to block IP addresses with too many failed login attempts.
- Running Security Advisor to make sure there are no weak passwords in the system.
- Enabling the Firewall in Control Panel while allowing publicly facing ports only when necessary.
- Finally, enable two-step verification (2SV).
- Based on Synology’s general advice, cloud multi-versioning should allow defenders to roll back to the same or previous versions of the same files. Or, better still, make regular offline backups.
Critically, on the topic of remote access, ensure it isn’t enabled via RDP when it shouldn’t be – or at all.
Naked Security has documented numerous attacks targeting RDP in recent times and provided advice on securing this protocol across a range of services, including NASs.
Sophos Intercept X Ransomware
Remember, the NAS ransomware attacks discussed here depend on weakly secured remote access to succeed. Close that door and you’ve blocked their way in.
We urge you to read the SophosLabs 2019 Threat Report, in which Sophos researchers analyze the state of play in cybercrime today, including a section on ransomware.
Finally, visit sophos.com to read more about anti-ransomware technologies, including Sophos Intercept X.
